MT Shapes - MT6x5
MT shapes are structural tees split from M shapes, carrying the lighter weights and smaller sizes available in the M series. They serve the same general purpose as WT shapes — truss chords, light built-up sections, and miscellaneous fabrications — wherever a lighter, smaller tee section is more appropriate than one cut from a full-size W shape.
Nearby Sections
Dimensions
| Property | Value |
|---|---|
| Nominal Weight | 5.0 |
| Depth of Section | 5.99 |
| Width of Section | 3.25 |
| Web Thickness | 0.149 |
| Flange Thickness | 0.18 |
| Kdet Dimension | 0.5 |
Full sortable table: Dimensions table for this family
Section Properties
| Property | Value |
|---|---|
| Ix | 5.62 |
| Zx | 2.45 |
| Sx | 1.36 |
| rx | 1.96 |
| Iy | 0.517 |
| Zy | 0.509 |
| Sy | 0.318 |
| ry | 0.594 |
| J | 0.0145 |
| Cw | 0.0202 |
| ro | 2.71 |
| H | 0.572 |
Full sortable table: Section properties table for this family
