W14x873 – W Shapes - American wide flange beams

W14x873 is 23.6 in (599 mm) deep with an 18.8 in (478 mm) wide flange, and weighs 873 lb/ft (1299.2 kg/m).

Wide-flange (W) shapes are the most widely used structural steel section in North American construction — an I-shaped profile with flanges that are parallel-faced and constant in thickness, connected by a web running the full depth of the section. That shape puts the bulk of the material as far from the neutral axis as possible, giving W shapes an excellent strength-to-weight ratio for resisting bending. They're specified as beams, columns, and everything in between, across virtually every building type — from single-storey warehouses to high-rise frames — and in bridges, platforms, and heavy equipment supports. The wide range of depths and weights available in the AISC series means there's a W shape suited to almost any span or load, from light floor framing through to the heaviest deep columns carrying a high-rise's gravity loads.

AutoCAD, MicroStation and OpenBuildings Designer CAD Outsource Services. Request a Quote Today!

Dimensions

PropertyValue
Nominal Weight (lb/ft)873.0
Depth of Section (in)23.6
Width of Section (in)18.8
Web Thickness (in)3.94
Flange Thickness (in)5.51
Kdet Dimension (in)6.1875
T Dimension (in)11.25

Full sortable table: Dimensions table for this family

Section Properties

PropertyValue
Ix (in⁴)18100
Zx (in³)2030
Sx (in³)1530
rx (in)8.39
Iy (in⁴)6170
Zy (in³)1020
Sy (in³)656
ry (in)4.9
J (in⁴)2270
Cw (in⁶)505000
rts (in)6.04
ho (in)18.1

Full sortable table: Section properties table for this family
