HSS10-3/4x1/2 (HSS10.75x.500) – HSS Shapes - Round

HSS10-3/4x1/2 is a 10.75 in (273 mm) diameter round hollow section with a 1/2 in (13 mm) nominal wall, weighing 54.79 lb/ft (81.5 kg/m).

Round HSS are closed, circular tube sections, sharing the torsional and biaxial strength advantages of rectangular HSS but in a circular profile that's often preferred where appearance matters — exposed columns, canopy supports, and architectural framing — as well as more utilitarian uses like handrail posts and bollards. The circular shape distributes compressive and torsional loads evenly in every direction, making round HSS a strong, materially efficient choice wherever a round column or post is wanted rather than a square or rectangular one.

AutoCAD, MicroStation and OpenBuildings Designer CAD Outsource Services. Request a Quote Today!

Dimensions

PropertyValue
Nominal Weight (lb/ft)54.79
Outside Diameter (in)10.75
Nominal Thickness (in)0.5

Full sortable table: Dimensions table for this family

Section Properties

PropertyValue
Ix (in⁴)199
Zx (in³)49.2
Sx (in³)37
rx (in)3.64
Iy (in⁴)199
Zy (in³)49.2
Sy (in³)37
ry (in)3.64
J (in⁴)398
C (in³)74.1

Full sortable table: Section properties table for this family
