MT Shapes
Welcome to our MT shapes free CAD downloads page! Here you'll find all Tees Cut from M shapes described by the AISC Steel shapes database (V14.1). Sort the table below according to any property and select a CAD file to download using the reference links in the left-most column.
You can also purchase all our CAD data in one easy download, containing the shapes as individual files or AutoCAD Design Center files - just click here to visit our Shop.
| Imperial Reference | Metric Reference | Nominal Weight | Depth of Section | Width of Section | Web Thickness | Flange Thickness | K Dimension |
|---|---|---|---|---|---|---|---|
| (Click on link to download) | lb/ft (kg/m) | d in (mm) | b in (mm) | tw in (mm) | tf in (mm) | k in (mm) | |
| MT 6.25x6.2 | MT 159x9.70 | 6.20 (9.70) | 6.27 (159) | 3.75 (95.3) | 0.155 (3.94) | 0.228 (5.79) | 0.563 (14.3) |
| MT 6.25x5.8 | MT 159x8.65 | 5.80 (8.65) | 6.25 (159) | 3.50 (88.9) | 0.155 (3.94) | 0.211 (5.36) | 0.563 (14.3) |
| MT 6x5.9 | MT 155x8.8 | 5.90 (8.80) | 6.00 (152) | 3.07 (78.0) | 0.177 (4.50) | 0.225 (5.72) | 0.563 (14.3) |
| MT 6x5.4 | MT 155x8.05 | 5.40 (8.05) | 5.99 (152) | 3.07 (78.0) | 0.160 (4.06) | 0.210 (5.33) | 0.563 (14.3) |
| MT 6x5 | MT 155x7.45 | 5.00 (7.45) | 5.99 (152) | 3.25 (82.6) | 0.149 (3.78) | 0.180 (4.57) | 0.500 (12.7) |
| MT 5x4.5 | MT 125x6.7 | 4.50 (6.70) | 5.00 (127) | 2.69 (68.3) | 0.157 (3.99) | 0.206 (5.23) | 0.563 (14.3) |
| MT 5x4 | MT 125x5.95 | 4.00 (5.95) | 4.98 (126) | 2.69 (68.3) | 0.141 (3.58) | 0.182 (4.62) | 0.563 (14.3) |
| MT 5x3.75 | MT 125x5.6 | 3.75 (5.60) | 5.00 (127) | 2.69 (68.3) | 0.130 (3.30) | 0.173 (4.39) | 0.438 (11.1) |
| MT 4x3.25 | MT 100x4.85 | 3.25 (4.85) | 4.00 (102) | 2.28 (57.9) | 0.135 (3.43) | 0.189 (4.80) | 0.563 (14.3) |
| MT 4x3.1 | MT 100x4.6 | 3.10 (4.60) | 4.00 (102) | 2.28 (57.9) | 0.129 (3.28) | 0.177 (4.50) | 0.438 (11.1) |
| MT 3x2.2 | MT 75x3.3 | 2.20 (3.30) | 3.00 (76.2) | 1.84 (46.7) | 0.114 (2.90) | 0.171 (4.34) | 0.375 (9.53) |
| MT 3x1.85 | MT 75x2.75 | 1.85 (2.75) | 2.96 (75.2) | 2.00 (50.8) | 0.098 (2.49) | 0.129 (3.28) | 0.313 (7.95) |
| MT 2.5x9.45 | MT 65x14.05 | 9.45 (14.1) | 2.50 (63.5) | 5.00 (127) | 0.316 (8.03) | 0.416 (10.6) | 0.813 (20.7) |
| MT 2x3 | MT 50x4.45 | 3.00 (4.45) | 1.90 (48.3) | 3.80 (96.5) | 0.130 (3.30) | 0.160 (4.06) | 0.500 (12.7) |
